10 kW horizontal axis wind turbine, fiberglass blades, off grid and grid connected energy storage system for wind solar complementarity
● Adopting a low-speed permanent magnet generator and a direct drive gearbox free transmission design.● Has multiple certifications such as CE and ISO9001, as well as multiple intellectual property patents.● The intelligent mechanical brake, electromagnetic brake, and automatic adjustment of wind angle with independent intellectual property rights of the company provide multi-level safety protection, ensuring the safe and…
| Power: |
10kW |
|---|---|
| System Type: |
Horizontal Wind Turbine |
-
Start-up wind speed2m/s
-
Working wind speed2.5-20m/s
-
Survival wind speed45m/s
-
Rotor diameter5.6m
-
Blade3pcs reinforced fiber glass
-
Blade length2.75cm
-
Rated voltageAC 220/240/380v
-
Tower type9m tower
-
Generator type3-phase AC PMG
-
Weight270kg
● Adopting a low-speed permanent magnet generator and a direct drive gearbox free transmission design.
● Has multiple certifications such as CE and ISO9001, as well as multiple intellectual property patents.
● The intelligent mechanical brake, electromagnetic brake, and automatic adjustment of wind angle with independent intellectual property rights of the company provide multi-level safety protection, ensuring the safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data.
