100kW Three Leaf Permanent Magnet Direct Drive Small and Medium sized Wind Turbine Manufacturer Horizontal Axis Yaw
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission ●Dual brake ,yawing, mechanical brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing
| Power: |
100kW |
|---|---|
| System Type: |
Horizontal wind turbine |
-
Start-up wind speed2m/s
-
Working wind speed2.5-20m/s
-
Survival wind speed45m/s
-
Rotor diameter24m
-
Blade3pcs Fiberglass-reinforced fiber glass
-
Blade length10.5m
-
Shell materialStainless Steel
-
Rated RPM60 r/m
-
Rated voltageAC380V
-
Top net weight5.1 ton
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission
●Dual brake ,yawing, mechanical brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing
