1kW household wind turbine suitable for farms or rooftops, starting at low wind speeds, easy to install
● The overall components are lightweight, flexible, and easy to lift, install, and disassemble. ● Multi level safety protection such as electromagnetic brakes and automatic adjustment of windward angle with independent intellectual property rights of the company, ensuring safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data. ● Adopting a…
Power: |
1000W |
---|---|
System Type: |
Horizontal Wind Turbine |
-
Start-up wind speed2m/s
-
Working wind speed2.5-30m/s
-
Rotor diameter2.2m
-
Blade3pcs reinforced fiber glass
-
Blade length110cm
-
Shell materialCasting aluminum alloy
-
Generator type3-phase AC PMG
-
Rated voltage24/48V
-
Tower type6m guy wire tower
-
Weight26kg
● The overall components are lightweight, flexible, and easy to lift, install, and disassemble.
● Multi level safety protection such as electromagnetic brakes and automatic adjustment of windward angle with independent intellectual property rights of the company, ensuring safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data.
● Adopting a direct drive permanent magnet generator with upwind direction, automatic adjustment of wind direction, and no gearbox transmission design, the whole machine has low starting wind speed, small size, light weight, beautiful appearance, and low operating vibration.
