20 kW small generator, low-speed permanent magnet generator, mechanical brake, automatic adjustment of windward angle
● Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission. ●Dual brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing. ●Long life span design by using superior aluminum…
| Power: |
20kW |
|---|---|
| System Type: |
Horizontal wind turbine |
-
Start-up wind speed2m/s
-
Working wind speed2.5-18m/s
-
Cut-in wind speed2.5m/s
-
Cut-out wind speed15m/s
-
Rotor diameter8m
-
Blade3pcs reinforced fiber glass
-
Blade length3.8m
-
Speed regulation & protectionYawing + electromagnetic brake+pitch control
-
Rated voltageAC 220/240/380v
-
Suggested tower height18m
-
Weight620kg
-
Rated RPM170r/m
● Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission.
●Dual brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing.
●Long life span design by using superior aluminum alloy and cast steel in accurate die‐casting tech and the anti‐corrosion treatment for all kinds of circumstances.
