30kW wind turbine, active pitch control, mechanical brake, factory shipped
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission ●Dual brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing ●Long life span design by using superior aluminum…
| Power: |
30kW |
|---|---|
| System Type: |
Horizontal Wind Turbine |
-
Start-up wind speed1.5m/s
-
Working wind speed2-20m/s
-
Rated wind speed9.4m/s
-
Rotor diameter12m
-
Blade3pcs reinforced fiber glass
-
Blade length5.8cm
-
Rated RPM120r/m
-
Weight1200kg
-
Generator type3-phase AC PMG
-
Rated voltageAC 380v
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission
●Dual brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing
●Long life span design by using superior aluminum alloy and cast steel in accurate die‐casting tech and the anti‐corrosion treatment for all kinds of circumstances
