A 50kW electronically controlled wind turbine has a high wind energy utilization rate
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission. ●Dual brake ,yawing, mechanical brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing.
| Power: |
50kW |
|---|---|
| System Type: |
Horizontal wind turbine |
-
Start-up wind speed2m/s
-
Working wind speed2-20m/s
-
Rotor diameter15.5m
-
Shell materialStainless Steel
-
Rated RPM80r/m
-
Weight2300-2500kg
-
Generator type3-phase AC PMG
-
Speed regulation & protectionElectromagnetic brake Mechanical brake Yawing
-
Rated voltageAC 380V
-
Peak power55kw
●Excellent power output performance.High efficient synchronized PMG generator with low starting torque. Lower RPM rotational speed avoid the risk of over speed malfunction and bring lower noise emission.
●Dual brake ,yawing, mechanical brake protection systems as reliable passive self‐furling and electromagnetic brake. Equipped with high quality NSK brand sealed bearing.
